A. We use high power 2W LED as the light source, R/G/B type can bring excellent light effects and brilliant colors.
B. There are two parts for the wall washer, first part is light body and the other one includes power supply and controller box, which makes this wall washer different with other wall washers.
C. It has smaller weight and stable quality and it is easy for maintance. Wall washers can be connected by 3-pin cable hand in hand, so very easy for installation.
D. There are 14 kinds of build-in programs which can be operated at the DMX windown. This wall washer can also be controlled by outside DMX 512 controller or super DMX Console to achieve more different lighting effects.
Basic specification
|
Item
|
Slim DMX Wall washer
|
|
Part No.
|
JJW-WWHX12V-S
|
JJW-WWHX24V-S
|
JJW-WWHQ12V-S
|
JJW-WWHQ24V-S
|
|
Dimension(mm)
|
507*108*72mm
|
993*108*72mm
|
507*108*72mm
|
993*108*72mm
|
|
|
12pcs
|
24pcs
|
12pcs
|
24pcs
|
|
Power consumption(W)
|
24W
|
48W
|
24W
|
48W
|
|
Weight(kg)
|
2.3kg
|
3.5kg
|
2.3kg
|
3.5kg
|
|
Control Way
|
Build-in Control mode, Control box,
|
|
Main material
|
Aluminum
|
|
IP Rate
|
IP65
|
|
Lens angle
|
50 degree
|
|
Input Voltage
|
AC100~240V,50~60Hz
|
|
Work Voltage
|
24VDC
|
|
Color temperature(K)
|
6000-6500(Pure White)
2800-3300(Warm White)
|
|
Rendering index
|
CRI>75
|
|
Lifespan(h)
|
>30,000
|
|
Ambient Temperature℃
|
-20℃ ~ +45℃
|
The Connection method
Method one：
Method two:
|
