Energy saving, save up to 70-80% power than fluorescent tubes.
Ultra-slim, only 12.7mm thickness.
Refined workmanship with good corner seam joint.
Excellent thermal management and refined aluminum, lengthen the life span of led light.
Long life span, more than 5 years.
Good lighting consistency, no dark spot.
New high efficient (95%) constant current driver. which can work under unstable voltage
Parameter:
| Part NO. |
LED Brand |
LED Quantity |
Power |
Lumen |
Beam Angle |
Work Voltage |
Work
Temperature |
Color |
| JJW-PL600X600W4-D |
SMD3014 |
576pcs |
60W |
3155lm |
120° |
24VDC |
-20~50℃ |
WW/CW/PW |
Dimension of JJW-PL300X300W2-D:
Relative Spectral Energy Distribution:
Installation:
This product should be installed by trained electricians.
Check integrality of the products when unpack the packing.
The distance between the light and any flammable materials must not be less than 0.2m.
The distance between the upper part of the installed light and the ceiling must not be less than 2cm.
Make sure the working voltage of the panel is 24VDC.
Please read and follow up the installation drawing carefully before the installation.
Package:
Application:
Hotels.
Conference / Meeting rooms.
Factories & Offices.
Commercial Purposes.
Residential / Institution Buildings.
Schools, Colleges & Universities.
Supermarket Lighting.
|
