There are 107,639dots per area of Indoor Fullcolor LED Display panel PH5 , of which the pixel size is 5mm, with 3 In 1 SMD LED chips imported from Japan, to achieve SMD technology. The grayscale of each is 256, and 16,777,216 kinds of colors in total. Dynamic scanning technology is used to ensure the stability of images, the precision of display effect and variety of animation; cabinets are made of aluminium alloy, so it's much lighter. On the other hand, LED panel can display text, pictures, animation as well as video, and the display effect is no longer restricted by the high-capacity of contents, because we own the top technology in the industry through ten-year’s research and development.

P5 Indoor display Cabinet and LED Display module Structure





Pixel Pitch

5mm

Module Resolution

32×32

Module Size

160×160mm

Physical Density

40'000 pixels/㎡

LED Arrangement

3IN1

LED Type

SMD 3528

Drive Mode

1/8 Scan

Cabinet Size

800×640×150 mm

Cabinet Weight

35KG
